Carbon Steel Pipe


Carbon Steel Pipe

Size: 1/4" (8mm)-80" (2000mm);Thickness: 2.11mm-60mm.

SCH: SCH10,SCH20,STD,SCH40,SCH60,XS,SCH80,SCH100,SCH120,SCH160,XXS.

Coating: 3PE Coating,3PP Coating,FBE Coating,Epoxy Coating,Special Painting.

Length: 3m-12m.

Standards: API 5L, API 5CT, ASTM A53, ASTM A106, ASTM A179, ASTM A192, ASTM A252.

Standard Type of pipe Class Grade
API SPEC 5L ISO 3183 SMLS PLS1 L245B, L290 X42, L320 X46, L360 X52, L390 X56, L415 X60, L450 X65, L485 X70
PLS2 L245N BN, L290N X42N, L320N X46N, L360N X52N, L390N X56N, L415N X60N, L360Q X52Q, L390Q X56Q, L415Q X60Q, L485Q X70Q
PLS2/PLS2 Sour Environment L245NS BNS, L290NS X42NS, L320NS X46NS, L360NS X52NS, L390NS X56NS, L415NS X60NS, L360QS X52QS, L390QS X56QS, L415QS X60QS, L485QS X70QS
Standard Description
API 5L for use in conveying gas, water, and oil in the natural gas and oil industries, and covers seamless and welded steel line pipe.
API 5CT for casing and tubing
ASTM A53 for Pipe, Steel, Black and Hot-Dipped, Zinc-Coated, Welded and Seamless
ASTM A106 for Seamless Carbon Steel Pipe for High-Temperature Service
ASTM A179 for Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser Tubes
ASTM A192 for Seamless Carbon Steel Boiler Tubes for High-Pressure Service
ASTM A213 for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A252 for Welded and Seamless Steel Pipe Piles
DIN 17175 seamless steel pipes are used in boiler installations, high-pressure pipelines and tank construction and special machinery for both high temperature and high-pressure devices.
DIN 1629 specifies the Seamless Circular Tubes of Non Alloys Steels with Special Quality Requirements.
DIN 2391 for Cold Drawn High Precision Seamless Tube
DIN 2458 Welded Steel Pipes in Unalloyed and Low Alloy Steels for Supply Purposes
EN 10210 Seamless steel tubes for pressure purposes
BS 3059 Steel boiler and superheater tubes
JIS G3454 Carbon steel pipes for pressure service
